EE 206: Circuits I
Lab Kits
Lab Kit Parts: Contents of the lab kits are listed below. The source of each item varies year by year based upon where we can find the lowest price in quantities of 100 or so.
|
Oscilloscope
Hantek 6022BE Digital Oscilloscope Portable PC Based 2 Channels 20MHz USB Oscilloscopes: Amazon: $65.90 |
|
Function Generator
1HZ-500KHZ DDS Functional Signal Generator, Seesii DDS Function Low Frequency Signal Generator Sine/Triangle/Square/Sawtooth Waveform. Amazon - $29.99 |
|
|
Multimeter
Vpro850L Digital Multimeter DC AC Voltmeter, Ohm Volt Amp Test Meter, Electric Tester Ohmmeter with Diode and Continuity Detector, Backlit Display and Insulated Rubber Case Kickstand (varies with kits) Amazon: $10.88 |
|
Rechargable 9V batteries
EBL Rechargeable 9V Lithium Batteries, 5400mWh USB 9 Volt Li-ion Batteries Long-Lasting(2 Pack) Provides 9V and +/- 9V for circuits Amazon: $15.99 |
|
Resistor Kit Resistor Kit 1 Ohm-1M Ohm with 5% 1/4W Carbon Film Resistors Assortment Amazon: $19.99 (kit varies) |
|
MCP602 Op-Amp
2.7V to 6.0V single sided supply op-amp Digikey: $0.61 (qty 1) LM2904P Op Amp +/- 1.5V to +/- 13V op-amp Digikey: $0.17 ea (qty 1) |
|
|
NPN Transistor
2N3904 Bipolar (BJT) Transistor NPN 40 V 200 mA 300MHz 625 mW Through Hole TO-92 Digikey: $0.044 qty 3 |
|
IRF510PBF N-Channel MOSFET
IRF510 N-Channel 100 V 5.6A (Tc) 43W (Tc) Through Hole TO-220AB Digikey: $0.56 (qty 1) IRL620PBF Power MOSFET N-Channel 200 V 5.2A (Tc) 50W (Tc) Through Hole TO-220AB Digikey: $2.53 (qty 1) |
|
|
|
Capacitors
10uF, Aluminum Electrolytic (qty 4) 0.1uF, Ceramic (qty 3) 15pF, Ceramic (qty 1) |
|
LEDs
Red diffuse LED (qty 1) Green diffuse LED (qty 1) |
|
Alligator Clips
qty 2 wires (random color) |
|
9V Battery Connector
qty 2 |
